. Model Proton 1000W Article no. BDF-1000C EAN code 4,71071E+12 Weight (without/with package) 2.58 kg / 3.08 kg AC Input 100-240V / 15.0A Frequency 50-60Hz +5V 23A +3.3V 23A +5V & +3.3V combined 140W +12V 1 996W / 83.0A P.F. >0.9 -12V 0.5A / 6.0W +5VsB 3.0A / 15W Maximum Power 1000W 20+4 PIN ATX 1 8 PIN EPS (4+4) 1 8 PIN EPS 1 8 PIN PCIe (6+2) 6 SATA 9 MOLEX 3 FLOPPY 1 24PIN ATX 500 8 PIN EPS (4+4) 550 8 PIN EPS 550 8 PIN PCIe (6+2) 3x 500/150 SATA 3x 450/150/150 MOLEX 450/150/150/150 FLOPPY Molex Specification ATX 12V 2.3 Form factor PS II Efficiency 80 PLUS® Bronze Dimension (DxWxH) 160mm x 150mm x 87mm PFC Active PFC (0.9) Fan 140mm silent fan Security AFC (Automatic Fanspeed Control) OCP (Overcurrent Protection) OPP (Overload Protection) OTP (Over Temperature Protection) OVP (Overvoltage Protection) SCP (Short-circuit Protection) SIP (Surge & Inrush Protection) UVP (Undervoltage Protection)
