. Performance Model Photon Gold 650W Article no. GDP-650C-RGB EAN code 753263075895 Weight (without/with package) 2,12 kg/ 2,52 kg AC Input 200-240V / 5A Frequency 47 - 63Hz +5V 20A +3,3V 20A +5V & +3,3V combined 120W +12V 1 53A / 636W +12V 2 - +12V 1 & +12V 2 combined - P.F. >0,9 -12V 0,3A / 3,6W +5VsB 2,5A / 12,5W Maximum Power 650W Connectors 20+4PIN ATX 1 8 PIN EPS (4+4) 1 8 PIN PCIe (6+2) 4 SATA 6 MOLEX 3 FLOPPY 1 +5V RGB LED 1 Cable length 20+4PIN ATX 550 8 PIN EPS (4+4) 550 8 PIN PCIe (6+2) 2x 550/150 SATA 2x 550/150/150 MOLEX 550/150/150/150 FLOPPY Molex +5V RGB LED 550 Features Specification ATX 12V 2.3 Form factor PS II Efficiency >90% Lightning modes 14x dynamic modes integrated Dimension (DxWxH) 160 mm x 150 mm x 87 mm PFC Active PFC (0,9) (only 230V) Fan 140mm silent RGB Rainbow fan Security UVP (Undervoltage protection) OVP (Overvoltage protection) SCP (Short-circuit protection) OPP (Overload protection) AFC (Automatic Fanspeed Control) SIP (Surge & Inrush Protection) Warranty 24 Months
